Angel's Smile monogram
Angel’s Smile
DENTAL CARE CENTER
DRAWING
260262-03R
DATE
July 2026
LOCATION
12257 S 800 E, Draper, UT 84020
SHEET
1 of 1
SIGNAGE RECOMMENDATION
Entrance sign — illuminated replacement panel
Replaces concept 260262-03 — mounts to existing customer-provided poles
PROPOSED — OPTION {{ optionLetter }} ON EXISTING WALL & POLES (NTS)
Existing entrance wall
AS monogram
Angel’s Smile
DENTAL CARE CENTER
ENTRANCE
8’-0”
4’-0”
A — CHARCOAL · SHOWN ILLUMINATED · RECOMMENDED
Monogram, push-thru lit
Angel’s Smile
DENTAL CARE CENTER
ENTRANCE
B — WARM OFF-WHITE
Gold AS monogram
Angel’s Smile
DENTAL CARE CENTER
ENTRANCE
C — DEEP GOLD
Off-white AS monogram
Angel’s Smile
DENTAL CARE CENTER
ENTRANCE
SCOPE OF WORK
  • Remove existing “Newcastle School” sign (dispose)
  • Manufacture & install one new illuminated replacement cabinet, 8’-0” × 4’-0”
  • Mount cabinet to existing customer-provided poles
MATERIALS & ILLUMINATION
  • .090 aluminum cabinet, 5” deep, square corners; face painted per selected option — A Charcoal #3F4245 (recommended), B Warm Off-White #F7F5F2, C Deep Gold #A8875D
  • Monogram & all copy: routed face, ½” push-thru trans white plex with vinyl overlay per color schedule; directional arrow points to entrance at right
  • Warm-white LEDs (3000K) housed in cabinet; visible disconnect; 120V by others
COLOR SCHEDULE
Warm Gold
#C4A177
Deep Gold
#A8875D
Charcoal Ink
#3F4245
Warm Off-White
#F7F5F2
Angel’s Smile Dental Care Center — practice of Dr. Oksana Bailey, Draper, UT
TYPE: BODONI MODA / MONTSERRAT  ·  BRAND STANDARD PALETTE
