Replaces concept 260262-01 — concept only, on-site survey required

• Manufacture & install one set of roof-mounted halo-lit channel letters with monogram, on a square-cornered backer cabinet, approx. 8’-0” × 3’-0”, centered between the brick columns (approx. 12’-0” apart)
• Cabinet face color per selected option A / B / C
• Survey required; building modifications in progress — concept only

• Backer cabinet: .090 aluminum on 2” square tube frame, square corners; painted per option — A Charcoal #3F4245 (recommended), B Warm Off-White #F7F5F2, C Deep Gold #A8875D
• Reverse channel letters, 3” aluminum returns; monogram faces brushed Warm Gold (PMS match to #C4A177); “Angel’s Smile” & “Dental Care Center” flat-cut, Charcoal on light faces / Warm Off-White on charcoal face
• Warm-white LEDs (3000K) halo onto cabinet; remote power supply; visible disconnect; 120V by others
• Cabinet on support posts fastened to structural framing; all roof penetrations flashed & sealed

Angel’s Smile Dental Care Center — practice of Dr. Oksana Bailey, Draper, UT

TYPE: BODONI MODA / MONTSERRAT  ·  BRAND STANDARD PALETTE
